Mainboard ASUS AMD B550 SAM4 MicroATX 1xPCI-Express 3.0 1x 1xPCI-Express 3.0 16x 2xM.2 1xPCI-Express 4.0 16x Memory DDR4 Memory slots 4 1xHDMI 1xDisplayPort 2xUSB 2.0 1xUSB type C 5xUSB 3.2 1xPS 2 1xOptical S PDIF 1xRJ45 5xAudio port TUFGAMINGB550M-PLUS

AMD B550 Micro-ATX motherboard with AM4 socket, DDR4 support up to 4800 MHz, PCIe 4.0, dual M.2 slots, USB 3.2 Gen 2 Type-A/Type-C, 2.5 Gb Ethernet, HDMI, and optimized cooling.

ASUS

133,71€
€110.50 (bez PVN)

AMD B550 | SAM4 | Micro-ATX | DDR4 | 4800/4600/4466/4400/4266/4133/4000/3866/3733/3600/3466/3333/3200/3000/2800/2666/2400/2133 MHz | Memory slots 4 | 1xPCI-Express 3.0 1x | 1xPCI-Express 3.0 16x | 1xPCI-Express 4.0 16x | 2xM.2 | 1xHDMI | 1xDisplayPort | 2xUSB 2.0 | 5xUSB 3.2 | 1xUSB-C | 1xPS/2 | 1xOptical S/PDIF | 1xRJ45 | 5xAudio port | USB 2.0 | USB 3.2 | Serial | SATA 3.0 | Video Depending on CPU | Audio | LAN Gigabit | RAID SATA 0, 1, 10

AMD B550 (Ryzen AM4) micro ATX gaming motherboard with PCIe 4.0, dual M.2, 10 DrMOS power stages, 2.5 Gb Ethernet, HDMI, DisplayPort, SATA 6 Gbps, USB 3.2 Gen 2 Type-A and Type-C, and Aura Sync RGB lighting support

  • AMD AM4 socket: Ready for 3rd Gen AMD Ryzen™ Processors
  • Enhanced power solution: 8+2 DrMOS power stages, ProCool connector, military-grade TUF components, and Digi+ VRM for maximum durability
  • Comprehensive cooling: VRM heatsinks, PCH fanless heatsink, M.2 heatsink, hybrid fan headers and Fan Xpert 2+ utility
  • Next-gen connectivity: PCIe 4.0 M.2, USB 3.2 Gen 2 Type-A and Type-C support
  • Made for online gaming: 2.5 Gb Ethernet, TUF LANGuard and TurboLAN technology
  • Realtek S1200A codec: Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in
  • AI noise-canceling microphone: Provides crystal-clear in-game voice communication
Unit Box Height 0.07
Unit Box Length 0.28
Unit Box Width 0.27
PCI-Express 3.0 1x 1
PCI-Express 3.0 16x 1
PCI-Express 4.0 16x 1
M.2 2
HDMI 1
DisplayPort 1
USB 2.0 Yes
USB 3.2 Yes
USB-C 1
PS/2 1
Optical S/PDIF 1
RJ45 1
Audio port 5
Serial Yes
SATA 3.0 Yes
Chipset AMD B550
Socket SAM4
Form Factor Micro-ATX
Memory type DDR4
Frequency speed 2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000/4133/4266/4400/4466/4600/4800MHz
Memory slots 4
Integrated video Depending on CPU
Integrated audio Yes
Integrated LAN Gigabit
RAID SATA 0, 1, 10
Units per Shipping Box 10
Unit Calculated Volume 0cubm
Product Net Weight 1kg
Unit Calculated Weight 1kg
SKU: ASUS-TUFGAMINGB550M-PLUS Category:
